FAQ
We are specializing in prototyping, mold fabrication, and injection molding.
We do painting, shielding, pad printing, silk-screen printing, ultra-sonic welding, thermal staking, gluing, assembly, and testing to support the production building too.
Video for Mold Fabrication –
Video for Injection Molding –
More videos -
We do CNC machining, 3D printing, reaction injection molding, vacuum molding, metal stamping, and die casting for prototyping and low volume production.
Video for CNC machining –
Video for 3D printing –
More videos about prototyping –
Mold Design, Mold Material Selection, Machining the Mold, Electrode Manufacturing, EDM Operations, Heat Treatment, Polish or/and Texture, Assemble the Mold, and Trial Runs
Article for detailed procedures -
Video for key steps of making a mold -
Good mold design and validation, professional gating/venting/cooling, precise CNC and EDM machining, fine polishing and texture, and experienced assembly.
Our tooling designs are typically tailored for extended usage, offering a minimum of 500k shots, corresponding to SPI mold class 102 standards. If your production volume exceeds this, we can accommodate you with SPI mold class 101, designed for 1 million shots or more. Conversely, for more cost-effective solutions suited to lower-volume products, we offer SPI class 103 molds, which are optimized for a minimum of 100k shots.
An injection molding machine melts plastic, shoots it into a mold, cools it, opens the mold, and ejects the solid plastic part.
Animation for how an injection molding machine works.
The expected tolerance range for injection molded parts can vary depending on factors like material, design, and machine capabilities. Generally, tolerances of ±0.05 mm to ±0.20 mm are common in the industry. Please send us your drawings, and we will conduct an evaluation to assess the tolerance of all dimensions.
The time required to build a plastic injection mold can vary widely based on the complexity of the mold, its size, and design intricacy. In general, mold production can take anywhere from
2 weeks to 10 weeks.
The cost of an injection mold can vary significantly depending on the complexity of the mold, the size of the part, the type of material, and the number of cavities in the mold. In general, a set of mold costs $2k to $100K.
Yes, we make DME standard molds for USA customers and HASCO standard molds for Europe customers.
We typically employ hot runner systems from renowned manufacturers such as Mold-Masters, Hasco, Husky, Synventive, and Yudo. The selection depends on factors like your company's location and specific requirements. Our goal is to choose a hot runner system that ensures the quality of the part and you receive optimal support and service based on your needs and location.
Absolutely. We have experience shipping our molds and injection molded parts to various international destinations, including the USA, Canada, Germany, Italy, and more. Our comprehensive service includes managing all necessary paperwork and handling the transportation process. Additionally, we offer flexible shipping options, such as EXW, FOB, DDU, and DDP, tailored to meet our customers' specific requirements. Your global logistics needs are in capable hands with us.
About Incoterms.
Conformal cooling is an advanced method used in manufacturing, particularly in injection molding. It involves the design and 3D printing of cooling channels that conform precisely to the shape of a mold. This enables more efficient and uniform heat dissipation, resulting in reduced cycle times and improved product quality.
For air shipment, it typically takes 2-5 days for standard service or 7-10 days for a more economical option.
If you opt for sea freight, the shipping time generally falls in the range of 25-35 days, with exact times dependent on the specific state within the USA where the delivery is destined.
For air shipping, it usually takes 2-5 days for standard service or 7-10 days for a more economical option.
For sea Freight, the timing is 30-40 days.
It takes 20-25 days to take the train.
Maps of how your products are being shipped from us to your facility.
For high-performance parts, our materials of choice include PPSU, PEI, PEEK, and PPS.
For general-purpose parts, we commonly work with materials like POM, PC, ABS, PP, PMMA, and PA.
The major properties of plastic materials are listed above.
The number of mold cavities we construct is influenced by the part's complexity and the required production volume. Typically, we produce molds with 1 to 8 cavities. However, for exceptionally high-volume production of small parts, we can create molds with up to 64 cavities.
A family mold, also known as a multi-cavity mold, is a type of injection mold that is designed to produce multiple different parts or variations of a part in a single molding cycle. It allows for the simultaneous production of several different components using the same mold, increasing production efficiency and reducing costs compared to making each part separately. Family molds are commonly used in applications where multiple related parts are needed for an assembly or where different variations of a product are required.
Yes. If your annual usage is relatively low, we can produce multiple parts simultaneously on a single mold, effectively reducing tooling costs. While this approach may result in slightly higher part prices, it offers cost-effective solutions for certain projects.
Creating two-color molds offers benefits like improved aesthetics, cost efficiency, durability, and design versatility. It streamlines production, reduces post-processing, and enhances part quality, making it a versatile choice for various applications.
More about 2-shot molds.
The daily production output of a mold varies based on factors like the number of cavities and the molding cycle time. For instance, a 2-cavity mold with a 40-second molding cycle can produce up to 3,960 parts per day during 22 hours of operation.
Companies create backup toolings to minimize production downtime, respond quickly to design changes, mitigate supply chain risks, optimize mold maintenance, expand production capacity, enhance reliability for critical applications, and potentially save costs associated with downtime and emergency repairs.
More information about the benefits of building backup molds.
It can be as big as 1.2 meters by 1.2 meters by 1 meter. Maximum weight is 5kgs.
We do painting, shielding, pad printing, silk-screen printing, thermal transferring, and water graphic.
More about finishing.
Yes, we apply PPG Spraylat 599 B3755 electrical shielding paint to the interior of medical part housings. Each part undergoes resistance testing to ensure it meets the required standard of 0.5 ohms per square inch, guaranteeing the highest quality.
Download the datasheet of PPG Spraylat 599 B3755 electrical shielding paint.
Do you handle final assembly and testing?
The Society of the Plastics Industry (SPI), now known as the Plastics Industry Association, established a standard for mold polishing and finishing that is widely recognized in the plastics industry. GoodTech MFG uses SPI mold polish standards to categorize the surface finish quality of molds used for plastic injection molding, which directly impacts the appearance and texture of the molded parts.
1.Temperature Control: The control of barrel temperature, nozzle temperature, and mold temperature is crucial to the injection molding process.
2.Pressure Variables: Plasticizing pressure and injection pressure play a significant role in determining the quality and characteristics of the molded parts.
3.Cycle Timing: The production cycle, including the duration of each phase, is a critical factor in achieving desired results in plastic injection molding.
4.Mold Design and Quality: The design and quality of the mold and tooling used in the process are paramount for achieving precision and consistency in molding outcomes.
1.Injection Unit:
Precision Control: The machine should offer precise control over injection speed, pressure, and volume to accommodate different materials and part specifications.
Injection Capacity: A range of injection capacities to handle various part sizes and shot volumes.
Screw Design: The injection screw design should match the material properties and the desired molding outcomes.
2.Clamping Unit:
Clamping Force: Adequate clamping force to securely hold the mold during injection.
Platen Size: Sufficient platen size to accommodate the mold and part dimensions.
Parallelism: Proper alignment and parallelism of the platens to ensure uniform clamping pressure.
3.Control System:
Intuitive Interface: A user-friendly interface with easy-to-use controls for setting parameters, monitoring processes, and making adjustments.
Closed-Loop Control: Advanced control systems that offer closed-loop feedback for temperature, pressure, and position control.
Process Monitoring: Real-time process monitoring and data logging capabilities for quality assurance.
4.Hydraulic System:
Efficiency: Energy-efficient hydraulic systems to minimize energy consumption.
Oil Filtration: Effective oil filtration and cooling systems to maintain hydraulic system integrity.
Noise Control: Low-noise hydraulic pumps and components for a quieter working environment.
5.Heating and Cooling:
Barrel and Nozzle Heating: Precise temperature control for the barrel and nozzle to accommodate different materials.
Mold Temperature Control: Integration with mold temperature control systems for consistent part quality.
6.Safety Features:
Safety Interlocks: Interlocks and safety mechanisms to protect operators from potential hazards.
Emergency Stop: Easily accessible emergency stop buttons for immediate shutdown in case of emergencies.
Safety Standards Compliance: Adherence to industry safety standards and regulations.
7.Robust Construction:
Frame and Base: Sturdy frame and base construction to minimize vibration and maintain machine stability.
Durability: High-quality materials and components for long-lasting performance.
1.Design Precision: The mold's design must be accurate and precise to produce parts with the desired dimensions and features. This includes considerations for part geometry, cooling channels, gate placement, and venting.
2.Material Selection: Choosing the right material for the mold is critical. Typically, molds are made from tool steels or alloys that can withstand high temperatures and provide durability.
3.Surface Finish: A smooth and polished mold surface reduces the likelihood of defects and improves the appearance of the molded parts. Proper surface finishing techniques, like polishing and texturing, are essential.
4.Cooling System: Efficient cooling is crucial to control cycle times and ensure consistent part quality. Well-designed cooling channels within the mold help maintain uniform temperature distribution.
5.Gate and Runner Design: The placement and design of gates and runners affect material flow and part quality. Proper gate and runner design minimize waste and avoid defects like flash.
6.Ejector System: An effective ejector system ensures that molded parts are ejected cleanly and without damage. Properly designed ejector pins, sleeves, and lifters are essential components.
7.Venting: Adequate venting is necessary to allow air and gases to escape from the mold cavity during injection. Proper venting reduces the risk of defects like burns or voids in the parts.
8.Tolerance Control: Maintaining tight tolerances in mold manufacturing is critical to achieving consistent part dimensions and quality.
